MEN-3510 is a managed 8-port, 10/100/1000 RJ45 downlink, and 2-port, FX/GbE SFP ports uplink, designed for broadband indoor office applications with basic needs in network infrastructure. The RJ45 type console port allows outbound network troubleshooting when networks go wrong. The USB port, designed to save configuration files, save system log files, and upgrade firmware, reduces network downtime and operational costs. This device is compatible with third-party devices and for scalable topologies. To keep regular internet speeds this device uses the Quality of Service (QoS) protocol to balance the use of bandwidth. It meets the requirements of triple-play broadband services along with low latency streaming - TV, internet, and phone. The management features allow safe, easy access and configuration of this device, using the web GUI and command line. It is designed to continue working during sudden power cuts with the help of an emergency battery parallel to the DC power jack input. To reduce the need for continuous maintenance, the fanless design of this switch avoids the accumulation of debris in the device, which also allows it to operate silently and hinder noise disturbances. The temperature operation of 0°C~50°C (32°F~122°F) allows for indoor network room in-rack or cabinet storage.
Non-stop Network with Redundant Power Supply
Powered by both AC and DC with battery backup option to ensure non-stop operation.
Multicast Video Service Support
IGMP (Internet Group Management Protocol) snooping for regulation of multicast traffic and MVR (Multicast VLAN Registration) for communication with hosts residing on different VLANs in a Layer 2 network.
Efficient Traffic Prioritization
Effective QoS mechanisms for priority assignment and transmission of dedicated traffics to specific applications.
Efficient Network Monitoring and Management
SNMP (Simple Network Management Protocol) v1/v2c/v3 and RMON (Remote Monitoring) for real-time traffic analysis, remote monitoring, and management.
Loop Avoidance and Redundant Link Feature
Equipped with redundancy protocols such as STP (Spanning Tree Protocol) and RSTP (Rapid Spanning Tree Protocol) to prevent loop formation and provide redundant connectivity.
USB Port
USB port for easy plug-n-play firmware upgrade, configuration, and syslog backup.
Standards
IEEE 802.3
10BASE-T
IEEE 802.3u
100BASE-TX
IEEE 802.3ab
1000BASE-T
IEEE 802.3u
100BASE-FX
IEEE 802.3z
1000BASE-SX/LX
IEEE 802.3
Nway Auto-negotiation
IEEE 802.3x
Flow Control
IEEE 802.3ad
Link Aggregation
IEEE 802.3az
Energy Efficient Ethernet (EEE)
IEEE 802.1AB
LLDP
IEEE 802.1D
STP
IEEE 802.1w
RSTP
IEEE 802.1p
Class of Service
IEEE 802.1Q
VLAN Tagging
IEEE 802.1X
Port Authentication
Interface
Ports
8 x 10/100/1000BASE-T RJ45 Ports
2 x 100FX/GbE SFP Slots
1 x RJ45 Console Port
1 x USB Port
LED Panel
PWR, ALM, POST, 1000, LNK/ACT
Power
Input Voltage
Primary inputs: AC 100~240 50~60Hz,
15V DC Power Adapter
Redundant inputs: 12V Battery
Power Consumption
30W (System)
Mechanical and Environment
Housing
Metal Case
Mounting
Rack Mount
Operating Temperature
0°C~50°C (32°F~122°F)
Storage Temperature
-20°C~70°C (-4°F~158°F)
Operating Humidity
5 to 95% RH (non-condensing)
Storage Humidity
5 to 95% RH (non-condensing)
Weight
1.17 kg (2.58 lb)
Dimension (WxHxD)
268 x 44 x 128 mm (10.6 x 1.7 x 5 in)
.jpg)
Ordering Information
| Model | Description |
|---|---|
| MEN-3510 | Managed 8 x 10/100/1000 RJ45 & 2 x FX/GbE SFP Switch, w/ Internal AC Power |
| MEN-3510B | Managed 8 x 10/100/1000 RJ45 & 2 x FX/GbE SFP Switch, w/ Internal AC Power, Battery Charge Function Included |
*Specifications subject to change without prior notice.
